Wireless Handheld Android SDK POS Terminal With NFC Reader HCC-Z90

  • 1 - 49 Pieces
    $160.00
  • 50 - 99 Pieces
    $150.00
  • 100 - 499 Pieces
    $145.00
  • >=500 Pieces
    $135.00
Model Number:
HCC-Z90
Screen Size:
5 Inch
Lead Time:
Quantity(Pieces) 1 - 10 11 - 50 51 - 100 >100
Est. Time(days) 3 7 15 Negotiable
Customization:
Customized logo (Min. Order: 200 Pieces)
Customized packaging (Min. Order: 200 Pieces)

More

Graphic customization (Min. Order: 200 Pieces) Less
Samples - $160.00 /Pieces, 1 Pieces (Min. Order): Buy Samples
Loading...
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
HCCTG
After-sales Service Provided:
Video technical support, Field installation, commissioning and training, Field maintenance and repair service, No after-sales service, Online support
Warranty:
1 Year
Operation System:
Android 5.1/7.0
CPU:
1.1GHz
Touch Screen Type:
Capacitive Screen
Hard Disk Capacity:
RAM:1GB FLASH:8GB
Display screen:
5.0 inch screen touch
Resolution:
480*854
Communication:
4G+3G+2G+Bluetooth+WiFi+Hot Spot
Interface:
1 Micro USB+1 Serial port
Printer:
58mm thermal printer
Battery:
Lithium battery: 3600 mah, 3.7 V
Card Reader:
MSR+IC Chip+Contactless
Camera:
5 mega-pixel camera
General Certification:
CCC, FCC, CE
Payment Certification:
EMV L1/L2,PBOC L1/L2,non-connected EMV L1,QUICS,QPBOC L1/L2,UnionPay
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
General Packing For Wireless Handheld Android SDK POS Terminal With NFC Reader HCC-Z90
1 pc/box; Box Size: 7*25*17 cm; Weight: 1 kg;
10 pcs/carton; Carton Size: 36*27*44 cm; Weight: 7.5 kg;
Port
SHENZHEN,GUANGZHOU, HONGKONG
Lead Time :
Quantity(Pieces) 1 - 10 11 - 50 51 - 100 >100
Est. Time(days) 3 7 15 To be negotiated
Video Description

,

Wireless Handheld Android SDK POS Terminal With NFC Reader HCC-Z90



Introduction

HCC-Z90 Android smart POS, operating system Android 5.1, no buttons, full touch screen, 5.0-inch large screen, long standby, thermal paper printing, rear camera 500W pixels, front camera 30W pixels, achieve 2G / 3G / 4G / Wifi / Bluetooth communication, brush magnetic stripe card + inductive IC card + contact IC card, fine workmanship, top quality, expanding market choice, applicable to supermarket chains, chain restaurants, convenience stores, clothing stores, bakery shops Such cashiers, payments, invoicing and business management functions.



Features

Ø Android 5.1 depth system customization, quad-core high performance + financial grade security, dual CPU design.

Ø Low-power design, support sleep for 100 hours standby, can complete 500 transactions.

Ø Large-capacity lithium-ion battery, 5V mobile phone charging, support 58MM width paper roll high-speed printing.

Ø Concise fashion: 2CM to thin body Build industry benchmarks, bring ultimate comfort grip, customized LOGO, color, boot LOGO screen.

Ø Card type: three-track magnetic card, contact type CPU card, contactless card.

Ø Anti-disassembler function design, support remote firmware update.

Ø EMV / PBOC L1 & L2 certification, non-connected EMV / qPBOC L1 & L2, PCI / UnionPay point-of-sale terminal security certification, 3C, FCC, CE, RoHS certification.



Specification

Operating system

Android 5.1 secure payment system

RAM

RAM: 1GB EMMC: 8GB

CPU

Qualcomm Quad-Core ARM Cortex A7 processor clocked at 1.1GHz

Extended storage

Micro SD card interface

Monitor

5.0 inches, resolution 480*854

Touch screen

Capacitive touch screen, support for electronic signature

Printer

Built-in high-speed thermal printer

Paper roll: 58*30mm

Magnetic card reader

Supports 1/2/3 magnetic card channels, two-way card swiping

IC card reader

Compliance with EMV and PBOC specifications, support for Class A (5.0V), Class B (3.0V) or Class C (1.8V) cards

SAM card holder

1 Pcs

SIM card holder

2 Pcs

Contactless reader

Supports ISO/IEC 14443 Type A&B, Mifare cards, compliant with non-connected EMV/qPBOC, specification read status indicator

USB interface

1 Micro USB OTG, compatible with USB2.0 HS standard, 1 serial port

Communication method

2G, 3G and 4G, Wi-Fi, hot spot, Bluetooth communication

GPS

Supports built-in GPS

Camera

Rear 500W pixels, front 30W

Optional: front 200W

Bar code reader

Supports 1D/2D scanning

Multimedia

Support recording, support voice playback, support video playback / recording

Password keyboard

Built-in password keyboard (virtual keys)

Support DES, 3DES, RSA, SHA-256 and AES algorithms

Battery

Lithium battery: 7.4V 2800mAh

Power Adapter

Input: 110V~240V AC/50~60Hz

Output: 5V DC/2A

Universal Micro USB Interface

Machine size

191.6mm×80.2mm×46mm

Machine weight

424g

Package Size

240mm*162mm*70mm

Package weight

700g

Standard accessories

Power adapter, manual, warranty card, USB charging cable, charger (optional),Leather case (optional)

Certified

EMV L1/L2, PBOC L1/L2, non-connected EMV L1, QUICS, QPBOC L1/L2, UnionPay smart point-of-sale terminal authentication, 3C, FCC, CE.



POS Products
Certificates-POS



Our Factory-POS
FAQ



1. Are you manufacturer?
Yes, we are manufacturers. We have been in PC/POS/Mobile Payment product & Solution for Eight years.

We can provide OEM / ODM customized service according to our customers’ various application and demands.

2. Would you provide SDK for me?
Yes, we offer free SDK if you order sample. All the contents in a CD ROM with sample together.



3. What warranty for the products?

According to our warranty policy, we will provide 12 months warranty time from the shipment date for our all products (Excluded the consumable parts).

As for the mass order, we will provide certain proportion spare parts or RMA machine for local service.


4. What is the minimum order?
We accept one piece for standard products. If require OEM, will see detailed requirements and confirm MOQ to you from our sales department.

5. Can we get the free sample?

Sorry, generally we would not provide the free sample. If the customer confirm the specification and price, they can order the sample firstly for the testing and evaluation.

When they place the mass order, we can return the sample cost to the customers.


6. Do you accept Paypal?
Yes, we accept paypal. Besides, we accept Western Union, T/T, L/C Secure payment (Escrow Service from Alibaba)  and so on.

7. What's the delivery time?
Generally, sample can be shipped in 2-3 working days after payment. For quantity, theleading time will be 1-4 weeks depend on exact quantity.



8.Which way to deliver the goods?

By Express: DHL UPS TNT FEDEX or ARAMEX EMS E-packing.

By Sea: Inform us the Sea Port to check which ship line.

By Air: Inform us the Airport to check which flight.

Or pick up by the customers.



9. What the after sale service?

a. Our all products will provide 12 months warranty;

b. Enough stock spare parts for guarantee;

c. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;

d. As for the returned failure products, we will fix it and return to the customers in one week after we received it.
