24-Pin Dot Matrix Bank Passbook Printer-Olivetti PR2 Plus

  • 1 - 49 Units
    $350.00
  • 50 - 99 Units
    $345.00
  • 100 - 999 Units
    $340.00
  • >=1000 Units
    $335.00
Color:
Lead Time:
Quantity(Units) 1 - 50 51 - 100 >100
Est. Time(days) 7 14 Negotiable
Customization:
Customized logo (Min. Order: 100 Units)
Customized packaging (Min. Order: 100 Units)

More

Graphic customization (Min. Order: 100 Units) Less
Samples:
$350.00 /Units | 1 Units (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Products Status:
Stock, Used
Type:
Dot-matrix
Style:
Black And White
Use:
Document Printer
Interface Type:
Bluetooth
Max Paper Size:
210mm
Black Print Speed:
242 characters/sec(En:16.8CPI)
Color Print Speed:
none
Max. Resolution:
240 x 360 dpi
Brand Name:
HCCTG
Model Number:
PR2 plus 1
Place of Origin:
China
Technology:
24-pin dot matrix
Resolution:
240 x 360 dpi
Pitch:
10, 12, 15, 16.6, 17,1 cpi
Line length:
238,76 mm (94 columns at 10 cpi)
Line spacing:
1/5", 1/6", n/216", n/240"
Copies:
Original + 6 copies
Interfaces:
Standard: RS232 serial, IEEE 1284 parallel
Certifications & Regulatory:
CE, TV NRTL, FCC class A verified
Dimensions (W x D x H):
384 x 296 x 204 mm 15.12"x11.65"x8.03"
Weight:
10.5 Kg
Supply Ability
Supply Ability:
999 Unit/Units per Month HCC refurbished dot matrix olivetti pr2 plus passbook printer
Packaging & Delivery
Packaging Details
Nuetral Packing for 24-Pin Dot Matrix Bank Passbook Printer-Olivetti PR2 Plus
Port
Shenzhen,Guangzhou,Hongkong,shanghai
Lead Time :
Quantity(Units) 1 - 50 51 - 100 >100
Est. Time(days) 7 14 To be negotiated

24-Pin Dot Matrix Bank Passbook Printer-Olivetti PR2 Plus

General

Olivetti PR2 PLUS has been designed in different models from the entry-level version to the dual-side scanner model in order to satisfy multifunctional front-office applications. It is capable to print on all Bank forms from single-sheet and multiple-copy documents to passbooks. The Olivetti passbook printers PR2 PLUS offer complete solutions in bank teller environments.

Advantage
Extremely easy to use
Up to 560 character/sec in VHSD
Magnetic-stripe reading and writing, micro code line reading (CMC7 / E13B)
Can be configured as a single-side scanner or as a dual-side scanner for simultaneous front/back Scanning on A4 formats up to 600 dpi
Color casing available in black or gray
New ink ribbon of up to 10 million characters

Feature

Ÿ   One of the smallest and quietest models in its product class

Ÿ   Superior printing speeds

Ÿ   Management of all bank forms

Ÿ   Magnetic-stripe reading and writing

Ÿ   Single-side scanner or dual-side scanner configuration

Ÿ   Dual-side color scanning

Ÿ   Ultra-fast alignment



Specification

Technology

24-pin dot matrix

Resolution

240 x 360 dpi



OCR A-B, ROMAN, Sans Serif, Italic, Courier

Pitch

10, 12, 15, 16.6, 17,1 cpi

Printing speed at 10 cpi

VHSD: 560 cps HSD: 510 cps Draft: 370 cps
NLQ: 185 cps
LQ: 125 cps
BIM: 2000 dps

Line length

238,76 mm (94 columns at 10 cpi)

Line spacing

1/5", 1/6", n/216", n/240"

Copies

Original + 6 copies

Interfaces

Standard: RS232 serial, IEEE 1284 parallel and USB2.0
Optional: expansion slot

Emulations

Olivetti Standard, IBM PP & X24
Optional: IBM 4722/9068
IBM PP & X24
WINCOR 4915
EPSON LQ 2550
UNISYS EFP series

Noise level

< 54 dBA

Document Handling

(ISO 7779 with ECMA 132 text)

Feed width: 245 mm
Completely flat paper feed
Automatic insertion with auto border
Automatic document-thickness monitoring

Power consumption

Min. 6,5 W (9 W the scanner model)
Max. 85 W (printing)

Ribbon cartridge

10 million characters

Voltage

230V / 50Hz
115V / 60Hz

Certifications & Regulatory

CE, TUV NRTL, FCC class A verified

Options

MICR reader (CMC7, E13B)
Scanner

Dimensions (W x D x H)

384 x 296 x 204 mm
15.12" x 11.65" x 8.03"

Weight

10.5 Kg

Scanner



Resolution

600 dpi RGB color 24 bit

Scanning speed

Max 10" inch/sec.
3.3" full color








Printer Products

Certificates-Printer



Factory-Printer

FAQ



1. Are you manufacturer?
Yes, we are manufacturers. We have been in PC/POS/Mobile Payment product & Solution for Eight years.

We can provide OEM / ODM customized service according to our customers’ various application and demands.

2. Would you provide SDK for me?
Yes, we offer free SDK if you order sample. All the contents in a CD ROM with sample together.

3. What warranty for the products?

According to our warranty policy, we will provide 12 months warranty time from the shipment date for our all products (Excluded the consumable parts).

As for the mass order, we will provide certain proportion spare parts or RMA machine for local service.


4. What is the minimum order?
We accept one piece for standard products. If require OEM, will see detailed requirements and confirm MOQ to you from our sales department.

5. Can we get the free sample?

Sorry, generally we would not provide the free sample. If the customer confirm the specification and price, they can order the sample firstly for the testing and evaluation.

When they place the mass order, we can return the sample cost to the customers.


6. Do you accept Paypal?
Yes, we accept paypal. Besides, we accept Western Union, T/T, L/C Secure payment (Escrow Service from Alibaba)  and so on.

7. What's the delivery time?
Generally, sample can be shipped in 2-3 working days after payment. For quantity, theleading time will be 1-4 weeks depend on exact quantity.



8.Which way to deliver the goods?

By Express: DHL UPS TNT FEDEX or ARAMEX EMS E-packing.

By Sea: Inform us the Sea Port to check which ship line.

By Air: Inform us the Airport to check which flight.

Or pick up by the customers.



9. What the after sale service?

a. Our all products will provide 12 months warranty;

b. Enough stock spare parts for guarantee;

c. Professional engineers provide 7*24 online service; If required, our engineers can provide local service in field;

d. As for the returned failure products, we will fix it and return to the customers in one week after we received it.
