Dual Interface ISO14443 & ISO 7816 PC SC Compliant Smart Card Reader Sam Slot ACR1281U-C1

  • 1 - 9 Units
    $52.00
  • 10 - 99 Units
    $48.00
  • 100 - 999 Units
    $44.00
  • >=1000 Units
    $40.00
Model Number:
ACR1281U
Lead Time:
Quantity(Units) 1 - 50 51 - 100 >100
Est. Time(days) 7 14 Negotiable
Customization:
Customized logo (Min. Order: 200 Units)
Customized packaging (Min. Order: 200 Units)

More

Graphic customization (Min. Order: 200 Units) Less
Samples:
$52.00 /Unit | 1 Unit (Min. Order) | Buy Samples
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Guangdong, China
Brand Name:
HCCTG
Dimensions:
120.5 mm (L) x 72.0 mm (W) x 20.4 mm (H)
Weight:
150 g
Interface:
USB Full Speed
Operating Distance:
Up to 50 mm (depends on the tag type)
Supply Voltage:
Regulated 5V DC
Supply Current:
200mA (operating); 50mA (standby)
Operating Temperature:
0-50degree
Operating Frequency:
6Hz
Compliance/Certifications:
PC/SC, CCID, CE, FCC, RoHS
Name:
Chip card Reader Writer support credit and smart card ACR1281U-C1
Supply Ability
Supply Ability:
9999 Unit/Units per Month
Packaging & Delivery
Packaging Details
Neutral Packing For Dual Interface ISO14443 & ISO 7816 PC SC Compliant Smart Card Reader Sam Slot ACR1281U-C1
Port
Shenzhen,Guangzhou,Hongkong,Shanghai
Lead Time :
Quantity(Units) 1 - 50 51 - 100 >100
Est. Time(days) 7 14 To be negotiated

Dual Interface ISO14443 & ISO 7816 PC SC Compliant Smart Card Reader Sam Slot ACR1281U-C1

General

ACR1281U-C1 DualBoost II is the second generation of ACR1281 DualBoost Reader. It is a dual interface reader that can access any contact and contactless smart cards following the ISO 7816 and ISO 14443 standards. ACR1281U-C1 DualBoost II enables one to integrate conventionally separate and independent applications for contact and contactless technologies into one device and one card; it can be used for online transactions to settle payments securely using credit cards, and it can also be used for topping up contactless cards via automated fare collection in public transport. It provides the perfect complement to the "All-in-one Card" concept that combines many kinds of smart card applications in just a single card.

The DualBoost Series has PC/SC compliance for both contact and contactless interfaces. It makes the use of high-speed communication for contactless cards at a maximum of 848 kbps, which makes it suitable for highly demanding applications. It also provides intelligent support for hybrid and combo cards, such that it detects a contactless card even that has been incorrectly placed in the contact card slot. Lastly, the DualBoost has a built-in SAM slot for added security in both contact and contactless applications.

With additional features such as USB firmware upgradability, contact memory card support and extended APDU support, ACR1281U-C1 DualBoost II is a highly cost-effective, powerful all-in-one device that offers convenience and flexibility to many smart card applications.



Feature

1.      Compliance with PC/SC for contact, contactless and SAM card interfaces

2.      Compliance with CCID

3.      Supports major contactless smart cards that conform to ISO14443 Type A and B

4.      Built-in antenna for contactless tag access, with card reading distance of up to 50 mm (depending on tag type)

5.      Supports new Mifare Plus and DESFire EV1

6.      T=CL emulation for Mifare 1K/4K Cards

7.      Read/write speed of up to 848 kbps for contactless interface

8.      Built-in anti-collision feature (at least 1 card is detected when multiple cards are presented)

9.      Supports extended APDU

10.   Supports major contact smart cards that conform to ISO7816

11.   Supports memory cards such as SLE5528, SLE5542, etc.

12.   Read/write speed of up to 344 kbps for contact interface

13.   Durable landing type smart card connector

14.   Built-in SAM card slot

15.   Intelligent support for hybrid and combi cards

16.   Firmware Upgradable

17.   User-controllable monotone buzzer and LEDs

18.   USB Full Speed (12 Mbps)



Specification

Dimensions

120.5 mm (L) x 72.0 mm (W) x 20.4 mm (H)

Weight

150 g

Interface

USB Full Speed

Operating Distance

Up to 50 mm (depends on the tag type)

Supply Voltage

Regulated 5V DC

Supply Current

200mA (operating); 50mA (standby)

Operating Temperature

0-50 C

Operating Frequency

13.56 MHz

Smart Card Interface Support

ISO-7816 Class A, B and C (5V, 3V, 1.8V)

ISO-14443 Type A & B

Mifare

Compliance/Certifications

PC/SC, CCID, CE, FCC, RoHS, USB Full Speed

Microsoft ® WHQL: 2000, XP, Vista, 7

Operating System Support

Win 2000, Win XP, Win Vista, Win 7, Win Server 2003, Win Server 2008

Win XP x64, Win Vista x64, Win 7 x64, Win Server 2003 x64, Win Server 2008 x64, Win Server 2008 R2 x64

Mac

Linux



Application

1.      e-Government  and e-Healthcare

2.      e-Banking  and e-Payment

3.      Transportation

4.      Network Security

5.      Access Control

6.      Loyalty Program
